Double Beam Gantry Robot

Very large sheets need a wide and strong gantry. A single beam can bend under a wide span. That bending hurts handling accuracy. The Double Beam Gantry Robot uses two main beams. The two beams share the load. The frame stays rigid under heavy work. The two beams cross over the line. A cross brace connects them in the middle. The frame uses high-strength square steel. Aging treatment removes welding stress. The double-beam design carries more weight than a single beam. It fits very large sheets and heavy parts. Precision linear guides and servo drive give stable movement. It fits large laser cutting lines and heavy sheet metal lines. It can run 24 hours without a stop. A single suction cup with a single station follows the set path. It picks, moves, and places sheets automatically. The Double Beam Gantry Robot gives strong handling for heavy work.

The Double Beam Gantry Robot has a load of 60kg. The moving range is 5800mm by 5600mm. The X-axis travel is 5800mm. The Y-axis travel is 6000mm. The Z-axis travel is 2200mm. Positioning accuracy is ±0.02mm. The structure is a double-beam gantry. The drive uses X, Y, and Z servo linkage. It fits large lines and very large sheet handling. Travel, load, and fixture can be customized. The machine runs with no worker standing by. Before shipment, we do a full assembly and test in the factory. If conditions allow, buyers can send material for a test cut. We provide a complete test video. The machine ships with a manual, electrical drawings, a tool kit, and random spare parts. After debugging, our technicians train the site operators. The training covers daily operation and basic maintenance.

We support the Double Beam Gantry Robot with a clear service system. When a buyer reports a fault, we give a first solution within 1 hour. We use phone or video help first. Remote help can solve many common issues fast. If remote help fails, we send a technician. We tell the buyer the expected arrival time before the trip. During warranty, machine body quality problems get free repair and free replacement parts. Wearing parts and site environment problems are not free. The machine comes with a 2-year warranty and lifetime maintenance support.
